This product is handmade in Europe and can take up to eight weeks to arrive. No returns or exchanges accepted.
What This Is
A custom-sewn leather e-brake boot for your 1999-03 Mazda Protege. It replaces the factory boot and installs on your factory frame or trim. It is not a complete e-brake assembly.
What's Included
- Included: 1 leather e-brake boot, cut and sewn to order.
- Not included: e-brake handle, trim or hardware. You reuse your factory parts.
Before You Order
- Fits 1999-03 Mazda Protege.
- It's made to order, so it can take up to 8 weeks to arrive and can't be returned or exchanged. Please double-check your year, fitment, and colors before ordering.
- International shipping: every piece ships from Poland, so a $15 international shipping charge applies to each item at checkout.
Installation
Difficulty: Moderate | Tools: screwdrivers, basic hand tools, glue or a stapler depending on your frame
You'll remove the e-brake trim, move the new boot onto your factory frame, and reinstall.
▼ Click to Open / Close Step-by-Step Installation Guide (13 Steps)
Step 1. Begin by removing the shift knob. This is threaded, and should screw right off. Next, open the arm rest console, and remove anything that might be in it. The shift plate and the cupholder are all on piece. Tug from the end of the plate, lifting up and the whole plate will pop right off.
Step 2. There are several screws you will need to remove. The first 2 being right on the stock boot itself and two others that hold the entire console down.
Step 3. Unfortunately, in order to get to the other screws, you will have to remove the entire centre console. To do this pop off the caps both at the front and rear of the console. And remove the screws.
Step 4. Check to make sure the console is loose and you have unscrewed everything. Remove the old shift boot and replace it with the new one. You can re-use the stock trim pieces from the top of the boot, or simply replace them with a zip-tie (which is useful for aftermarket shift knobs that have the bottom more narrow than the stock ones).
Step 5. Pull up the e-brake cover. It will come off the center console.
Step 6. Pull the tabs from cover. Cut the leather to match the tabs in the rubber e-brake surround you have just removed. Pull the leather boot around the rubber surround and trim it to match the tabs - that's the easiest way. Glue the leather to the tabs if you want (Automotive GOOP works great - or any other epoxy-based glue).
Step 7. This is what it should look like.
Step 8. Reinstall the e-brake boot. Put the front-side tabs in, hold the e-brake boot and the center console piece together, slip the top of the e-brake boot over the handle and push the assembly back in until it pops into place.
Step 9. Open the armrest and remove the screws by the hinges.
Step 10. Spray the armrest with 3M spray-on adhesive. Turn the cover inside-out and place on the center of the armrest. The glue should be tacky enough to allow it to move until you get it on perfect. Work out the wrinkles to perfection.
Step 11. Turn the armrest over and make sure the edges are glued and rolled over.
Step 12. Use rubber bands to make the cover stay in place until the glue dries.
Step 13. Reinstall everything in the reverse order of removal and ENJOY!
Leather care: apply a leather conditioner with UV protection every 4-6 weeks to keep it from drying out and cracking.
Options & Pricing
Choose your material, colors, and stitching color in the options above. Add-on prices are added in the cart.
Material
- Regular Leather
- Perforated Leather
- Faux Alcantara
- Carbon Fiber Vinyl
Two-tone: choose a second color in the options above.
Style
- Quadruple Thread +$9
Quadruple stitching color applies to the outer lines of thread.
